Ge Appliances UUC136WCDBA 208-230V 36,000 Btu Side Discharge Air Conditioner Condensing Unit

Name: Ge Appliances UUC136WCDBA 208-230V 36,000 Btu Side Discharge Air Conditioner Condensing Unit
Brand: Ge Appliances
SKU: UUC136WCDBA
Availability: OutOfStock

Colors:

White

Call us at (800) 288-1647 for expert assistance in finding the perfect alternative.

Product variants

View full details

When Will I Get My Order?

208-230V 36,000 BTU Side Discharge Air Conditioner Condensing Unit Side-discharge configuration is perfect for installation in limited space.
Easier contractor equipment transportation and installation.
Sound-dampening features produce operation at noise levels as low as 52dB.
Compatible with many 24VAC thermostat.
Independent 3rd party coil match available.
Dimensions & Capacity Width: 40"
Height: 32 "
Depth: 17 1/2"
Cooling Power: 36000 btu

Compact Size
Light Weight
Quiet Operation
24V System
AHRI Matching Indoor Coil
See specification book for full heating, cooling, and system details

CAPACITY
Cooling BTUH (MAX)	35000 Btu
APPEARANCE
Color Appearance	White
POWER / RATINGS
Cooling Rated Capacity BTU/Hr	35,000
Minimum Circuit Amp	16
WARRANTY
Parts Warranty	10-Year Limited Parts and Compressor Warranty with Registration Limited 5-Year Parts and Compressor
WEIGHTS & DIMENSIONS
Net Weight	141.1 lb
Suction O.D. Refrigerant Line	3/4'
Liquid O.D. Refrigerant Line	3/8'
Overall Depth	17.5 in
Factory Charge (pounds)	7.6999998092651 lb
Overall Width	40 in
Overall Height	32 in
Approximate Shipping Weight	187.4 lb
FEATURES
Style	Side-Discharge
Model Type	Indoor
Refrigerant Type	R410A
Maximum Line Length (Ft/M)	82/25
ADP Model	HE35(6,9)48+TDR
Series	Side-Discharge
Maximum Height (Ft/m)	33/10
Temperature Range - Cooling Mode	50-115 F (10-46 C)
SEER	14.199999809265137
Compressor Type	Rotary
Maximum Fuse Size A	25
EER	12.2
Fan Speed RPM	900
Outdoor Noise Level	59 dBA
Outdoor Airflow CFM	2300
CFM with Rated Coils	1150
Product Type	Multi Zone Single Zone

Installation Instructions
