Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
Miele CleanCover
Miele's unique easy cleaning: The sealed, smooth surface prevents contact with the electrical components/motor.
Handcrafted In Germany
Know-how and craftsmanship: Our expertise goes into every ventilation hood, from development to finished product.
Active AirClean Filter
Efficient odor absorption: The disposable filter with active charcoal must be replaced regularly.
- Classic design - stainless-steel panel, 24 in (60 cm) wide
- LED strip for uniform lighting
- Efficient filtration- 10-ply stainless steel grease filters
- Safe and easy to clean - Miele CleanCover
- Recirculation mode - Active AirClean or Longlife AirClean filter
| Construction type | |
| Built-in ventilation hood | • |
| Operating modes | |
| Recirculated mode | Convertible |
| Recirculation conversion kit (order separately) | DUU 151 |
| Design | |
| Color | Stainless steel |
| Control panel | |
| Electronic controls | • |
| Cleaning convenience | |
| • | |
| Filter system | |
| Number of dishwasher-safe stainless-steel grease filters | 1 |
| Lighting | |
| LED ClearView lighting | • |
| Number x W | 1 x 3,0 W |
| Light intensity in Lx | 330 lx |
| Color temperature in K | 3500 Kelvin |
| Blower | |
| Dual-action blower | • |
| AC motor | • |
| Safety | |
| Safety shut-off | • |
| Technical data | |
| Canopy width in in. (mm) | 23 1/2 (596) |
| Canopy height in in. (mm) | 1 1/2 (36) |
| Depth of hood canopy in in. (mm) | 10 3/4 (273) |
| Minimum distance above electric cooktops in in. (mm) | 24 1/8 (610) |
| Minimum height above gas cooktop (max. 12.6 kW total power, burner 4.5 kW) in mm | 26 (660) |
| Net weight in lbs. (kg) | 31 (14.0) |
| Length of electrical wire in ft. (m) | 2 (0.8) |
| Standard plug fitted | • |
| Total connected load in kW | 0.35 |
| Voltage in V | 120 |
| Fuse rating in A | 15 |
| Frequency in Hz | 60 |
| Number of phases | 1 |
| Installation notes | |
| Vent connection at top | • |
